FTS 1050A vs. HP 5061A

Data file: /data/fts_1050a-hp5061a.dat
Last modified: 19:25:31 05-Sep-2015 (UTC)

MJD date range from 57074.850984 to 57270.809387
4704 readings over 195.96 days, tau0 = 3600 seconds

End-to-end phase change:26.516 s
Phase change per day:135.312 ms
Peak-to-peak phase range:29.333 s

Time difference (REF-DUT, last sample):26.100 s

Frequency offset (linear, R2=0.160):7.414E-07
Frequency offset (endpoints):1.566E-06


Raw Phase


Offset Removed

Peak-to-peak noise:32.396 s


Frequency


Overlapping Allan Deviation

TauADEV  TauADEV
3.60E+032.556E-03  2.30E+055.870E-05
7.20E+031.434E-03  4.61E+052.991E-05
1.44E+047.527E-04  9.22E+051.470E-05
2.88E+043.955E-04  1.84E+067.727E-06
5.76E+042.090E-04  3.69E+063.652E-06
1.15E+051.134E-04  7.37E+061.705E-06
