[time-nuts] Adafruit Ultimate GPS timing message arrival times

Mark Sims holrum at hotmail.com
Sat Jul 30 16:14:02 EDT 2016

A couple of people have asked about the poor message arrival time performance of the popular Adafruit Ultimate GPS receiver.   I modified Lady Heather to analyze the message arrival times using a histogram instead of a simple average.  When I looked at the histogram data (.01 msec resolution), I was rather shocked...  With an hour of data,  most receivers have maybe a couple dozen bins hit,  with the peak bin several hundred counts above the next lower peak.   The Adafruit had over 1800 bins hit, with the peak bin having six hits.   Attached is the histogram...  you probably don't want to use this receiver to drive a clock based upon message arrival times...
-------------- next part --------------
A non-text attachment was scrubbed...
Name: Adafruit.png
Type: image/png
Size: 36150 bytes
Desc: Adafruit.png
URL: <http://www.febo.com/pipermail/time-nuts/attachments/20160730/c848fed2/attachment.png>
