>> In the telecommunications world, stratum refers to the holdover
>> performance of an oscillator in the event of loss of synchronization.
>> Stratum 1, Stratum 2, Stratum 3, and Stratum 4 are the most typical. A
>> Stratum 1 clock has an accuracy of 1.0 x 10-11, Stratum 2 has an
>> accuracy of 1.6 x 10-8, Stratum 3 has an accuracy of 4.6 x 10-6, and
>> Stratum 4 has an accuracy of 3.2 x 10-5.
> That's frequency rather than time. Right?
> Isn't there also something about how long it has to be within the frequency spec?
> These are my opinions, not necessarily my employer's. I hate spam.
> time-nuts mailing list -- time-nuts at febo.com
> To unsubscribe, go to https://www.febo.com/cgi-bin/mailman/listinfo/time-nuts
> and follow the instructions there.
The ITU stratum 1 time error mask for optical and wired networks
is attached and shows the allowable time error over a given
sampling period to remain within the stratum 1 specification.
-------------- next part --------------
A non-text attachment was scrubbed...
Size: 15744 bytes
Desc: not available
Url : http://www.febo.com/pipermail/time-nuts/attachments/20070802/e06f07ca/attachment.gif
